Atess 30kw 50kw 100kw 120kw 150kw Three Phase Hybrid Solar Energy Storage Inverter

Products > Inverter > Atess 30kw 50kw 100kw 120kw 150kw Three Phase Hybrid Solar Energy Storage Inverter
    • 1
    • 2
    • 3
    • 4
    • 5
    • 6

Atess 30kw 50kw 100kw 120kw 150kw Three Phase Hybrid Solar Energy Storage Inverter

Customized packaging(Min. Order 10 sets)
Customized logo(Min. Order 10 sets)
Graphic customization(Min. Order 10 sets)
Supply Ability

  • Supply Ability

  • 20000000 Watt/Watts per Day

Packaging & Delivery

  • Packaging Details

    • Atess 30kw 50kw 100kw 120kw 150kw three phase hybrid solar energy storage inverter
    Wooden Pallet

  • Port

    • Shanghai, Ningbo

  • Lead Time:

  • Quantity(sets)1 - 10000>10000
    Est. Time(days)5To be negotiated
Product Introduction
Datasheet
ATESS
HPS30
ATESS
HPS50
ATESS
HPS100
ATESS
HPS120
ATESS
HPS150
AC (Grid-connected)
Apparent power
33kVA
55kVA
110kVA
132kVA
165kVA
Rated power
30kW
50kW
100kW
120kW
150kW
Rated voltage
400V
Rated current
43A
72A
144A
173A
217A
Voltage range
360V - 440V
Rated frequency
50/60Hz
Frequency range
45~55/55~65Hz
THDI
<3%
PF
0.8lagging~0.8leading
AC connection
3/N/PE
AC input
60kVA
100kVA
200kVA
240kVA
240kVA
AC(Off-grid)
Apparent power
33kVA
55kVA
110kVA
132kVA
165kVA
Rated power
30kW
50kW
100kW
120kW
150kW
Rated voltage
400V
Rated current
43A
72A
144A
173A
217A
THDU
≤2%linear
Rated frequency
50/60Hz
Overload capability
110%-10 mins
120%-1 min
DC (Battery and PV)
Max. PV open-circuit voltage
1000V DC
Max. PV power
45kWp
75kWp
150kWp
180kWp
225kWp
PV MPPT voltage range
480V-800V DC
Battery voltage range
at Max. charge power
450V-600V
500V-600V
500V-600V
517V-600V
500V-600V
Battery voltage range
352-600V
Max. charge power
45kW
75kW
150kW
180kW
225kW
Max. discharge power
33kW
55kW
110kW
132kW
165kW
Max. charge current
100A
150A
300A
350A
450A
Max. discharge current
93A
156A
313A
374A
467A
General Information
Protection degree
IP20
Noise emission
<65dB(A)@1m
Operating temperature
-25 °C~+55 °C
Cooling
Forced-air
Relative humidity
0-95% non-condensing
Maximum altitude
6000m (derate over 3000m)
Dimension (W/H/D)
700/1660/600
950/1860/750
1200/1900/800
Weight
355kg
610kg
948kg
1025kg
1230kg
Build-in transformer
Yes
Transfer between on/off grid
Automatic≤10ms
Standby consumption
<30W
Communication
Display
Touch screen
Communication
RS485/CAN
Certificate
CE , MEA , PEA , AS 4777.2，EN 61000-6-4:2007+A1:2011 , EN61000-6-2:2005 , EN62109-1:2010 , EN62109-2:2011 , EN 50549-1:2019 ,IEC62109.1 ,IEC62109.2, NRS 097-2-1:2017, G99, VDE-AR-N 4105:2018,DIN VDE V 0124-100:2020-06
Solar Storage System
Production line
Project Cases
Company & Exhibition
Service Team
Recommend Products
FAQ
Q1: How to insatll and use the solar inverter? A1: We have the English teaching manual and videos;All the videos about every step of solar inverter Disassembly, assembly, operation will be sent to our customers. Q2: What if I don't have export experience ? A2: We have reliable forwarder agent which can ship items to you by sea/air/Express to your doorstep.Any way, we will help you choose the most suitable shipping service. Q3:Can you provide the free shipping to sea port ? A3:Yes, we provide the free shipping to your convenient sea port.If you have agent in China, we can also ship it to them for free. Q4: How is your technical support? A4: We provide lifetime online support through Whatsapp/ Skype/ Wechat/ Email. Any problem after delivery, we will offer you video call anytime,our engineer will also go to oversea help our customers if necessary. Q5: How can I make sure it's a secure transaction ? A5: Alibaba can protect buyers' interest, all of our transation will go through alibaba platform.As you do the payment, the money will go directly to Alibaba bank account.After we send your the items and you comfirm the detailed information, Alibaba will release us the money. Q6: Can you get the the solar inverter customized for us ? A6: Of course, brand name, solar inverter color, designed unique patterns available for customization. Q7:How to become your agent? A7:Contact us through Alibaba, we will give you the best price and look forward to your greetings.
